Thermography Cat II

The Thermography CAT II Course builds on introductory thermography knowledge and develops the skills needed for more demanding inspections.

Participants explore the relationship between heat transfer, surface properties, camera performance and measurement accuracy. The course focuses on selecting appropriate inspection methods, compensating for measurement influences and evaluating thermal findings in their operating context.

Applications include electrical systems, rotating machinery, process equipment, insulation and building envelopes.

COURSE SYLLABUS

1. Applied Heat Transfer

• Conduction, convection and radiation in industrial equipment
• Thermal conductivity and thermal resistance
• Steady-state and transient thermal behaviour
• Thermal capacity and heating or cooling rates
• Interpreting surface temperatures in relation to heat flow

2. Infrared Radiation and Surface Properties

• Blackbody and real-surface radiation
• Emissivity and its dependence on material, finish and viewing angle
• Reflection and transmission
• Spectral considerations in infrared measurement
• Limitations when inspecting low-emissivity surfaces

3. Quantitative Temperature Measurement

• Selecting suitable quantitative inspection methods
• Practical approaches to estimating emissivity
• Determining reflected apparent temperature
• Applying atmospheric and distance compensation
• Comparing contact and infrared measurements
• Recording assumptions and measurement conditions

4. Camera Performance and Measurement Limits

• Thermal sensitivity versus temperature accuracy
• Spatial resolution and measurement resolution
• Field of view, target size and working distance
• Lens selection and focus
• Calibration, verification and equipment checks
• Recognizing measurements beyond the camera’s capabilities

5. Measurement Error and Uncertainty

• Identifying major sources of error
• Evaluating the influence of incorrect parameter settings
• Repeatability and reproducibility
• Environmental and operating-condition effects
• Reporting meaningful temperature differences
• Avoiding unsupported measurement precision

6. Infrared Windows and Transmissive Materials

• Transmission through infrared windows
• Material and wavelength compatibility
• Window transmission compensation
• Effects of contamination, angle and window condition
• Inspection limitations and documentation

7. Thermal Image Analysis

• Selecting suitable level, span and colour palettes
• Spot, area and line-profile analysis
• Comparing radiometric images
• Distinguishing reflections from actual thermal anomalies
• Evaluating thermal gradients and patterns
• Tracking changes under comparable operating conditions

8. Electrical Inspection Applications

• Resistive heating in connections and contacts
• Load-related temperature differences
• Comparative assessment of phases and similar components
• Cooling, enclosure and access limitations
• Correlating thermal findings with electrical measurements
• Prioritizing findings using operating context and equipment criticality

9. Mechanical and Process Applications

• Thermal patterns in motors, bearings and drive systems
• Friction, lubrication and cooling-related indications
• Pumps, couplings and belt-driven equipment
• Steam systems, valves and process pipework
• Insulation deterioration and abnormal heat loss
• Confirming findings with complementary inspection methods

10. Building and Insulation Applications

• Thermal bridges and insulation discontinuities
• Air-leakage indications under suitable test conditions
• Moisture-related patterns and independent confirmation
• Solar loading, wind and weather effects
• Selecting appropriate inspection conditions
• Interpreting complex building-envelope patterns

11. Inspection Procedures and Quality Control

• Defining inspection objectives and acceptance criteria
• Selecting equipment and measurement settings
• Developing repeatable inspection instructions
• Recording load, environment and inspection limitations
• Reviewing data quality
• Supporting consistent work by inspection teams

12. Assessment, Reporting and Follow-Up

• Separating observations from diagnostic conclusions
• Evaluating severity using documented criteria
• Considering equipment criticality and operating conditions
• Preparing clear technical reports
• Recommending further testing and corrective action
• Verifying results after maintenance

WHO SHOULD ATTEND?

• Thermographers with introductory training and field experience
• Electrical and mechanical inspection personnel
• Condition-monitoring technicians
• Maintenance and reliability engineers
• Facility and building inspection professionals

RECOMMENDED BACKGROUND

Thermography CAT I training or equivalent knowledge is recommended. Practical experience operating a thermal camera will help participants apply the course concepts.

LEARNING OUTCOMES

After completing this course, participants should be able to:

• Select appropriate methods for quantitative thermal inspections
• Apply emissivity, reflection and transmission compensation
• Evaluate measurement limitations and uncertainty
• Interpret thermal findings in their operating context
• Develop repeatable inspection procedures
• Assess findings using documented criteria
• Prepare diagnostic reports with clear recommendations

COURSE INFORMATION

Provider: LGP INSTITUTE
Delivery Method: Online
Language: English
Course Fee: USD 140
Separate Online Examination Fee: USD 90

Candidates who successfully complete the examination receive a certificate issued by LGP Institute, Türkiye.

For more information and registration, contact LGP INSTITUTE today.
